220W Semi Flexible Solar Panels

The 220W Semi Flexible Solar Panel is designed for users who need high power output without the weight and bulk of traditional glass modules. Using high-efficiency monocrystalline solar cells, this panel delivers stable 220W performance while remaining thin, lightweight, and easier to handle during installation and daily use.

Applications For Motor Boats and Sailing Yachts For Yachts, Electric Boats, Cruise Ships For Buoy, Lighthouse, Deck, Boat Roof, Boat Railing For Marine transportation industry, Marine application products

  • Model NumberedBS220-FS-M(E)
  • BrandBright Solar
  • Max Power Pm(Wp)220W
  • Max Working Voltage (Vmp) 18V
  • Solar Cell182*182mm/Mono
  • Product Dimension1552*770*4.5mm
  • Cells Efficiency22.5%

Online Procurement
Name*
Email Address*
TEL*
Company/Unit Name*
Quantity*
Content*
Submitting…
Submission Successful! We will arrange the connection shortly.
Submission Failed! Please try again later.
Invalid Email Address!
Invalid Phone Number!

Why choose a 220W Semi-Flexible Solar Panel?

H Series-BS220-FS-M(E)(images 1)

Walkable Design

Most Robust construction,Rugged and Tough design,can walk easily, Durable, Versatile,Suitable for deck installation

H Series-BS220-FS-M(E)(images 2)

Anti-slip design

UV resistant & shatter-proof polymer

H Series-BS220-FS-M(E)(images 3)

100% salt water resistant

Designed for Marine & maintenance-free, easy to install

H Series-BS220-FS-M(E)(images 4)

Double-sided ETFE design

All material in encapsulated inside, 100% fully waterproof

H Series-BS220-FS-M(E)(images 5)

Tough & Lightweight design

Marine Solar Panel only 4.60mm thick, reduces weight

H Series-BS220-FS-M(E)(images 6)

Deck installation design

Easy to install on flat deck

BS220-FS-M(E) Solar Panel Parameters

Electrical Specifications

  • Power220W
  • Max Working Voltage (Vmp)18V
  • Max Operating Current (Ipm)12.2A
  • Open Circuit Voltage (Voc)22.5V
  • Short Circuit Current (Isc)13A

Physical Dimensions

  • Product Size1552*770*4.5mm
  • Weight6.82 KG

Model & Warranty

  • Model Number BS220-FS-M(E)
  • BrandBright solar
  • Product Name220W Semi Flexible Solar Panel
  • Warranty3 Years

Solar Cell Performance

  • Cell Type182 × 182 mm Mono
  • Efficiency22.5%
