160W Non Glass Lightweight Solar Panel

Thin Frame Series

160W Non Glass Lightweight Solar Panel -Thin Frame Series, reinforced aluminum edge frame, delivering the conformability of a flexible panel with the handling ease, mounting security, and durability of a rigid frame.

The thin frame series is bordered by a lightweight, anodized aluminum frame. This frame only 5mm thick. and hardware, ensures perfect alignment during installation, and protects the panel’s vulnerable edges from peeling, lifting, or wind damage.

Hybrid Design Excellence: Get the best of both worlds—the conformability of a flexible panel, plus the structural integrity and easy mounting of a framed panel.

Secure & Simple Installation: The metal frame and the double-sided tape on the back of the drilled holes or panel allow for quick installation anywhere. No more worrying about corners lifting in high winds.

Edge Protection & Longevity: The aluminum frame shields the flexible substrate’s edges from moisture intrusion, physical abrasion, and delamination—significantly extending product life.

Professional, Finished Look: The framed edges provide a clean, defined outline, giving a more integrated and permanent appearance compared to a mat-like flexible panel.

Optimal Performance: High-efficiency cells ensure reliable power output, while the flexible core allows for dissipation of thermal stress, maintaining performance across temperatures.

• Model NumberBS160-SR-M(E)
• BrandBright Solar
• Max Power Pm(Wp)160W
• Max Working Voltage (Vmp)20.0V
• Max Operating Current(Ipm)8.00A
• Open Circuit Voltage (Voc)25.0V
• Short Circuit Current (Isc)8.51A
• Solar CellPERC Mono Solar Cell
• Efficiency22.5%
• Size1057*915*5mm
• Tolerance+3%
• Weight3.40 KG
