250W Non Glass Lightweight Solar Panel -Thick Frame Series

Applications:• For industry, agriculture, shipping and building sectors

Share to:

Model Number: BS250-FR-M(E)
Brand: Bright Solar
Max Power Pm(Wp): 250W
Max Working Voltage (Vmp): 20.00V
Solar Cell: 166*166mm/Mono
Product Dimension: 1714*704*35mm
Cells Efficiency: 22.5%
Warranty: 3 year

Specification Product Description Downloads

Model Number	BS250-FR-M(E)
Power	250W
Max Working Voltage (Vmp)	20.00V
Max Operating Current(Ipm)	12.50A
Open Circuit Voltage (Voc)	25.00V
Short Circuit Current (Isc)	13.30A
Product Size	171470435mm
Solar Cell	166*166mm/Mono
Efficiency	22.5%
Tolerance	+3%
Warranty	3 year
Weight	7.2 KG
