Home » Product » Flexible Solar Panel » L Series » 55w Sunpower Flexible Solar Panel L-Series

55w Sunpower Flexible Solar Panel L-Series

Applications: • For Driving at high speed van, camper • For camping, caravan, off-road and 4x4 • For Install curved surfaces • For industry, agriculture, shipping and building sectors
Share to:
  • Model Number: BS55-FT-S(E)
  • Brand: Bright Solar
  • Max Power Pm(Wp): 55W
  • Max Working Voltage (Vmp): 18.00V
  • Solar Cell: 161*161mm/Sunpower
  • Product Dimension: 575*535*3.1mm
  • Cells Efficiency: 24%
  • Warranty: 3 Year
contact us
Specification Product Description Downloads
Model BS55-FT-S(E)
Power 55W
Max Working Voltage (Vmp) 18.00V
Max Operating Current(Ipm) 3.05A
Open Circuit Voltage (Voc) 22.00V
Short Circuit Current (Isc) 3.28A
Product Size 575*535*3.1mm
Efficiency 24%
Tolerance 0~+3%
Warranty 3 Year
Weight 1.1 KG
Solar Cell 161*161mm/Sunpower

• Max 30% Flexibility
• Mostly lightweight solar panel
• 100% sea & salt water resistant
• DuPont ETFE Coating with UV Resistance & reduce slip risks
• 100% maintenance-free, easy to install
• 0~3% tolerance output power
• PERC Mono solar cells or SunPower with highest performance
• IP67 junction box cable output, sealed and fully waterproof
• Cable : 3m length cables or  2*1m with MC4 connectors
• 304 stainless steel eyelets or easy fixing and installation
• Gule solution for installation
• Rounded corners + plastic cover for protection
• Optional:blocking diode and bypass diode , avoid shadow
• Anti-Hotpot design
• 3 years warranty power output


Product information

  • Bright Solar Sunpower panel Specifications.pdf Download
